| 型号 Type |
额定一次电流 Rated Primary current (A) |
额定安匝数 Turn ampere turn |
穿心匝数 Turn through care |
准确级及相应额定输出 Accuracy classes And rated output (VA) | |||
| 0.2 | 0.5 | 1.0 | 10P6 | ||||
| LMZ1-0.5 | 5,10,20,50,100 | 100 | 1-20 | 5 | 7.5 | ||
| 15,30,75,150 | 150 | 1-10 | 5 | ||||
| 40,200 | 200 | 1-5 | |||||
| 300 | 300 | 1 | |||||
| 400 | 400 | 1 | |||||
| LMZJ1-0.5 | 5,10,15,20,30,40,50,75,100,150,200,300 | 300 | 1-60 | 10 | 15 | ||
| 40,200,400 | 400 | 1-10 | |||||
| 500 | 500 | 1 | 10 | ||||
| 600 | 600 | 1 | |||||
| 750 | 750 | 1 | |||||
| 1000,1250,1500,2000,3000,4000 | 1000-4000 | 1 | 15 | 20 | 30 | 10 | |
