| 型号 Type | 额定电压比 Rated voltage Ratio (kV/kV) | 准确级及相应 额定输出 Accuracy classes And rated output | 极限输出 Max output (VA) | 剩余绕组准确 及额定输出 With residual Voltage winding(VA) | 额定绝缘水平 Rated insulation Level (kV) | 额定频率 Rated frequency (Hz) | ||
| 0.2 | 0.5 |
1.0 | ||||||
| JDZX-27.5 | 27.5/√3/0.1/ √3/0.1/3 | 30 | 50 | 180 | 600 | 6P 100 | 31.5/80/180 | 50/60 |
| JDZX-35 | 35/√3/0.1/ √3/0.1/3 | 40.5/95/200 | ||||||
