| 型号 Type |
额定电压比(kV) Rated voltage ratio |
准确级组合 Accuracy classes Combination (VA) |
额定输出(VA) Rated output (VA) |
极限输出(VA) Max output (VA) |
额定绝缘水平(kV) Rated insulation Level (kV) |
| JDZ10-3A1 | 3/0.1 | 0.2 0.5 1 |
15 30 60 |
150 | 3.6/25/40 |
| JDZ10-6A1 | 6/0.1 | 7.2/32/60 | |||
| JDZ10-10A1 | 10/0.1 | 12/42/75 | |||
| JDZX10-3A1G | 3/√3/0.1/ √3/0.1/3 | 0.2/6P(3P) 0.5/6P(3P) 1/6P(3P) |
15/50 30/50 60/50 |
150 | 3.6/25/40 |
| JDZX10-6A1G | 6/√3/0.1/ √3/0.1/3 | 7.2/32/60 | |||
| JDZX10-10AG | 10/√3/0.1/ √3/0.1/3 | 12/42/75 |
