| 额定一次电流 Rated primary current (A) | 准确级组合及额定输出(VA) Accuracy classes and Rated output (VA) | 额定短时热电流 (kA)/时间(s) Short-time Thermal Current (kA/S) | 额定动稳定电流 (峰值)(kA) Rated dynamic current (kA Peak) | |||
| 0.2/10P10 | 0.5/10P10 | 0.2/0.5 | 10P10/10P10 | |||
| 15~300 | 10/30 | 20/30 | 10/20 | 20/20 | 150I1n | 375I1n |
| 400 | 10/40 | 15/40 | 10/15 | 20/20 | 63 | 130 |
| 500 | 10/40 | 15/40 | 10/15 | 25/25 | ||
| 600 | 10/50 | 30/50 | 10/30 | 30/30 | ||
| 800 | 15/50 | 30/50 | 15/30 | 30/30 | ||
| 1000~2000 | 20/50 | 50/50 | 20/50 | 40/40 | 80 | |
