型号
Type |
额定电压比
Rated voltage
Ratio (kV/kV) |
准确级或准确
级组合
Accuracy classes
Combination (VA) |
额定输出
Rated output
(VA) |
极限输出
Max output
(VA) |
额定绝缘水平
Rated insulation
Level (kV) |
备注
Remarks |
| JDZ10-3,6,10A2 |
3/0.1 |
0.2
0.5
1.0 |
15
30
60 |
150 |
3.6/25/40
7.2/32/60
12/42/75 |
同AZL10 |
| 6/0.1 |
| 10/0.1 |
| 3/0.1/0.1 |
0.2/0.2
0.2/0.5
0.5/0.5 |
10/10
10/15
15/15 |
150 |
3.6/25/40
7.2/32/60
12/42/75 |
| 6/0.1/0.1 |
| 10/0.1/0.1 |
| JDZX10-3,6,10A2 |
3/√3/0.1/√3/0.1/3 |
0.2/6P(3P)
0.5/6P(3P)
1.0/6P(3P) |
15/50
30/50
60/50 |
150 |
3.6/25/40
7.2/32/60
12/42/75 |
同AEL10 |
| 6/√3/0.1/√3/0.1/3 |
| 10/√3/0.1/√3/0.1/3 |
