型号
Type |
额定电压比(kV)
Rated voltage ratio |
准确级组合
Accuracy classes
Combination (VA) |
额定输出(VA)
Rated output (VA) |
极限输出(VA)
Rated output (VA) |
额定绝缘水平(kV)
Rated insulation
Level (kV) |
| JDZX11-20 |
13.8/√3/0.1/√3/0.1/3 |
0.2/6P(3P)
0.5/6P(3P) 1/6P(3P) |
30/100
80/100
150/100 |
400 |
18/55/105 |
| 15/√3/0.1/√3/0.1/3 |
| 15.7/√3/0.1/√3/0.1/3 |
| 20/√3/0.1/√3/0.1/3 |
24/65/125 |
| JDZXF11-20 |
13.8/√3/0.1/√3/0.1/√3/0.1/3 |
0.2/0.2/6P(3P)
0.2/0.5/6P(3P)
0.5/0.5/6P(3P) |
15/15/100
20/20/100
30/30/100 |
300 |
18/55/105 |
| 15/√3/0.1/√3/0.1/3/0.1/3 |
| 15.7/√3/0.1/√3/0.1/√3/0.1/3 |
| 20/√3/0.1/√3/0.1/√3/0.1/3 |
24/65/125 |
