35kV电压互感器 JDZX－35W

型号 Type	额定电压比 Rated voltage ratio	准确级组合 Accuracy classes Combination (VA)	额定输出(VA) Rated output (VA)	极限输出(VA) Max output (VA)	额定绝缘水平 (kV) Rated insulation Level (kV)
JDZXW-35	35/√3/0.1/ √3/0.1/3	0.2/6P(3P)	30/100	600	40.5/95/200
		0.5/6P(3P)	50/100
JDZXW-35	35/√3/0.1/ √3/0.1/3	0.2/0.2/6P(3P)	20/20/100	300	40.5/95/200
		0.2/0.5/6P(3P)	20/30/100
		0.5/0.5/6P(3P)	40/40/100
