10kV电流互感器 LZZQB6－10

额定一次电流 Rated primary current (A)	额定二次电流 Rated secondary current (A)	准确级组合 Accuracy classes combination	准确级及相应额定输出 Accuracy classes and Rated output (VA)			短时热电流 Short-time Thermal Current (kA/IS)	额定动稳定电流(峰值kA) Rated dynamic current (Peak kA)
			0.2	0.5	5P15
20	5或1	0.2/0.5 0.5/5P15 0.5/5P15	10	10	15	8	20
30						12.5	31.5
40						16	40
50						20	50
75						25	63
100				15	20	31.5	80
150.200.300						45	112.5
400.500				20	30
600.750			15	30	40
1000-1250						63	160
