| 额定一次电流 Rated primary current (A) |
额定二次电流 Rated secondary current (A) |
额定输出 Rated output (VA) |
额定短时热电流 (kA)/时间(s) Short-time Thermal current |
额定动稳定电流 (峰值)(kA) Rated dynamic current (kA Peak) |
| 15 |
0.2/0.5 0.2/10P15 0.5/10P15 02/10P10 0.5/10P10 10P10/10P10 |
30/50 30/30 50/30 30/50 50/50 30/30 |
3 |
8 |
| 20 |
4 |
10 |
| 30 |
6 |
15 |
| 40 |
8 |
20 |
| 50 |
10 |
25 |
| 75 |
15 |
37.5 |
| 100 |
21 |
52.5 |
| 150 |
31.5 |
80 |
| 200 |
31.5/2 |
80 |
| 300 |
31.5/4 |
80 |
| 400 |
0.2/0.5 0.2/10P15 0.5/10P15 02/10P10 0.5/10P10 10P15/10P15 |
50/50 50/50 50/50 50/50 50/50 25/25 |
| 500 |
| 600 |
| 800 |
| 1000 |
40/4 |
100 |
| 1200 |
| 1500 |
| 2000 |
